Petrochemical Industry

Petrochemical Applications

Oil drilling is very demanding because seals have to work under extreme conditions. If a seal fails, the resulting repairs and production stoppages are very costly.

Seals in drilling equipment can be exposed to harsh chemicals and gases — different hydrocarbons (including sulfonated ones), superheated steam, hydrogen sulfide (H₂S), carbon dioxide, methane, and amine-based corrosion inhibitors — plus very low or very high temperatures (below 0°C up to over 200°C) and high pressures.

To cope with so aggressive and diversified combinations the following features must be granted at the same time:

  • chemical resistance
  • outstanding physical properties
  • elasticity in a wide range of temperatures
  • resistance against explosive decompression (AED)

We have many years of experience fixing tough sealing problems in the Oil & Gas industry.

We’ve successfully provided sealing solutions for equipment such as:

  • Ball valves, gate valves, butterfly valves, regulating valves, plug valves, seat valves, check valves, metering valves, control valves

  • Valve actuators, blowout preventers (BOP), couplings for flexible pipes

  • Xmas trees, drill drives, marine cranes

anyseals offers a wide range of O-rings, rubber gaskets, and standard PTFE seals in sizes up to Ø 2300 mm (≈ 90 inches).

FKM, bisphenolic cured

Maximum thermal rating (+240°C), excellent resistance against hydrocarbons also aromatic, good physical properties, limited resistance to steam and H2S (max 2000 ppm). Special compounds for explosive decompression (AED).

FEPM, AFLAS®

Excellent thermal rating (+230°C),outstanding resistance against bases and H2S ( up to 30%), limited resistance to hydrocarbons and aromatic substances, limited low temperature flexibility. Special compounds for explosive decompression (AED).

HNBR

Maximum physical properties, good thermal rating (+160°C), good steam and H2S ( max 5000 ppm) resistance, limited resistance to aromatic hydrocarbons. Special compounds for explosive decompression (AED).

FKM, peroxide cured

Excellent thermal rating (+220°C), special grades for low temperatures, good resistance to bases, limited resistance H2S. Special compounds for explosive decompression (AED).

FFKM, evolast®

Outstanding thermal rating (+330°C), outstanding resistance towards aggressive chemicals, acids, organic and inorganic fluids, ketones, esters, solvents, amines, hot water and steam. Special compounds for explosive decompression (AED).
